Maxitronix-30in1-14

From ITL Wiki

This is project #14 of the Maxitronix-30in1.

The KiCad files for this project are here:

https://github.com/jj5/kicad-bench/tree/main/maxitronix/30in1/Maxitronix-30in1-14

See KiCad for some notes about my KiCad configuration.

Scans
